MIG WEDLERS

  • NEED TO KNOW:

    • New Model with Digital Design

    • Clear, Color Digital display

    • PowerSet mode for easy setup

    • 120V input IGBT inverter

    • Spool Gun Capable

    • 140 Amps Maximum Output

    • 25% Duty Cycle at 140 Amps

    • .023"-.030" Wire diameter

    • Stepless adjustment

    • 4" or 8" spool (2-12 lbs)

    • Euro-Quick Connect for MIG gun

    • Uses common 15 Series MIG gun consumables

  • NEED TO KNOW:

    • NEW! Digital Screen Design

    • NEW!  PowerSet Mode

    • NEW!  Stick Welding Mode

    • 120/240V Dual Voltage input IGBT Inverter

    • Spool Gun Capable

    • 200 Amps Maximum Output

    • 25% Duty Cycle at 180 Amps for MIG

    • 25% Duty Cycle at 160 Amps for Stick

    • .023"-.030" Stock Drive Roll Sizes

    • ,023:-.035" Solid wire capability (Opt.)

    • .030"-.045" Gasless Flux-Cored Capability(Opt.)

    • Easy Changeover of polarity for flux-cored use.

    • Stepless adjustment

    • 4" or 8" spool (2-12 lbs)

    • Euro-Quick Connect for MIG gun

    • Common 15 Series MIG gun consumables

  • NEED TO KNOW:

    • Digitally Controlled IGBT Inverter

    • 4.3" TFT LCD Color Display

    • Advanced PowerSet Mode

    • Multi-Process: MIG and Stick

    • Spool Gun ready

    • 15% Duty Cycle @ 230A  (MIG)

    • 35% Duty Cycle at 200A  (MIG)

    • Adjustable MIG Inductance and Burn Back Control

    • Up to a 8" spool (12 lbs)

    • Euro-Quick Connect 24 series gun

    • 120V/240V Dual voltage

    • Pre-flow and Post Gas Flow Control

    • Stick Hot Start and Arc Force Control

  • NEED TO KNOW:

    • Digitally Controlled IGBT Inverter

    • 60% Duty Cycle at 250A

    • 240V 1 and 3 Phase (plug not included)

    • Single and Double (Pulse on Pulse/Twin) MIG

    • DC Lift Start TIG Capable with optional gas valve torch

    • Stick function with E6010 capability

    • HD 4 roller driver roll system

    • Hold 8" (10-12 lbs)  or 12" (up to 44 lbs) spools

    • Euro Quick-Connect with 24 series MIG gun

    • Weld Steel, Stainless, Aluminum, or Bronze with Manual and Pulse MIG

    • Self Shielded Flux-Core Capable

    • Generation 2 Power Set mode makes setup easy

    • Aluminum Push/Pull Capable

    • 4.3" HD LCD Color Display

    • Easy to use and navigate screen and controls

    • All settings on single screen

    • Adjustable Inductance (MIG) and Arc Force (Stick)

    • Save and name up to 30 individual programs

    • Can use included U groove drive rolls and PTFE liner to weld aluminum if needed.

  • NEED TO KNOW:

    • Digitally Controlled IGBT Inverter

    • 4.3" TFT Color LCD display

    • Advanced PowerSet function (Synergic)

    • MIG/Stick function (inc.  Cellulose/E6010 types for Stick)

    • Gas Shielded Flux-Core Capable

    • Gasless Flux-Core Capable

    • Spool Gun ready

    • Spot Stitch Timer

    • Adjustable Pre/Post Flow

    • Adjustable Up/Down Slope of Wire Speed

    • Adjustable Start/End Wire Feed Speed

    • Inductance

    • Gas Purge and Wire Jog

    • Run In Setting

    • Spool Gun Compatible (Parker DSP 360)

    • Push-Pull Gun Compatible (Parker SGP 360A)

    • 275A MIG/200A Stick maximum output

    • 35% Duty Cycle at 275A MIG

    • 35% Duty Cycle at 200A Stick

    • .023"-.045" standard wire capability (Stock .035-.045")

    • Adjustable inductance/arc force

    • Memory/Program Function

    • Use 8" or 12" spools

    • Euro-Quick Connect for the 36 series MIG gun

  • NEED TO KNOW:

    • Digital IGBT Inverter construction

    • Single Pulse MIG/MIG/DC TIG/Stick

    • Synergic Pulse MIG/ Synergic MIG

    • Spool Gun and Push Pull Gun Ready

    • 60% Duty Cycle @ 275A MIG, 250TIG, 220A Stick

    • Adjustable MIG/Stick Arc Force

    • Save up to 30 programs

    • Live Lift Start for TIG

    • .035"-.045" Wire diameter

    • 36 Series Euro fast connect MIG gun

    • 12" spool (30-44 lbs) capacity

    • Synergic PowerSet function simplifies setup for all processes

  • NEED TO KNOW:

    • 315A @ 35% Duty Cycle

    • Digital, bright/contrasting 4.3" TFT LCD display

    • Large easy to read display number values for reading at a distance

    • Advanced Power Set Function provides workable settings based off user input

    • Included Under Carriage and Cylinder Rack

    • 240V 1 Phase operating input

    • 36 Series MIG gun

    • MIG/Stick function

    • Spot/Stitch Timer

    • Burn Back Control

    • Arc/Force Inductance

    • 2T/4T function

    • Gas Purge and Wire Jog

    • Run-In Feature

    • Spool Gun (Parker DSP 360) and Push Pull Gun (Parker SGP 360A) capable

    • Dual Shield capable in manual mode

    • Solidly E6010 capable with special settings for other rods

    • 12" roll capacity

    • 4 Roll Gear Driven Wire Feeder

    • Welding Cart included

  • NEED TO KNOW:

    • Heavy Duty IGBT Inverter Design and Performance

    • 60% Duty Cycle at 500A

    • Fast Open Root lay-in with close arc MIG

    • Single and Double Pulse with fast travel settings

    • Vertical Up Setting

    • Additional Advanced forms of MIG pulse

    • DC lift Start TIG with pulse

    • DC Stick

    • Weld Multiple metal types with MIG

    • Multiple MIG modes for most any type of welding

    • Low Spatter MIG

    • Spot Weld Setting

    • Water-Cooler

  • NEED TO KNOW:

    • Digital IGBT Inverter construction

    • 4.3" HD digital color screen

    • Up to 215A output for MIG and TIG

    • MIG/DC TIG/Stick/Spool Gun

    • DC Pulse TIG ( No MIG Pulse)

    • PowerSet Synergic Mode

    • 35% Duty Cycle @ 200 Amps MIG/TIG

    • Adjustable MIG/Stick Arc Force

    • Save and name multiple programs

    • Lock programs to prevent tampering

    • HF and Lift and Live Lift Start for TIG

    • .030"-.035" Wire diameter (Std.)

    • North 24 Series Euro quick connect style Gun

    • 4"-8" spool

    • Dual Voltage 120/240V

    • 6010 Stick Capable

    • Foot Pedal

  • NEED TO KNOW:

    • Digital IGBT Inverter construction

    • Single Pulse MIG/MIG/DC TIG/Stick

    • Synergic/Pulse MIG/Syn MIG/Pulse TIG function

    • Spool Gun and Push Pull Gun Ready

    • 60% Duty Cycle @ 275A MIG, 250TIG, 220A Stick

    • Adjustable MIG/Stick Arc Force

    • Save up to 30 programs

    • HF and Lift Start for TIG

    • .035"-.045" Wire diameter

    • 36 Series Euro fast connect MIG gun

    • 12" spool (30-44 lbs) capacity

    • Synergic PowerSet function simplifies setup

  • NEED TO KNOW:

    • Digital IGBT Inverter construction

    • MIG/AC/DC TIG/Stick/Plasma

    • Spool Gun Ready

    • PowerSet Menu for easy setup

    • 35% Duty Cycle @ 225A MIG,  35% @ 225A TIG,  60% @180A Stick, 60% @ 40A Plasma

    • Max Output 225A MIG/TIG, 180A Stick, 40A plasma

    • Adjustable MIG/Stick Arc Force

    • Save multiple programs

    • HF and Lift Start for TIG

    • .030"-.035" Wire diameter (larger optional drive rolls sizes and types available)

    • 24 Series Euro fast connect MIG gun

    • Blow back torch (IPT 40)

    • 8" spool (10 to 12 lbs)

    • Dual Voltage 120/240V

  • NEED TO KNOW:

    • Digital IGBT Inverter construction

    • MIG/AC/DC TIG/Stick/Spool Gun/ Push Pull

    • PowerSet Function makes setup quick and easy

    • 35% Duty Cycle @ 225A MIG,  35% @ 200A TIG,  35% @185A Stick

    • Max Output 225A MIG/TIG and 185A Stick

    • Adjustable MIG/Stick Arc Force

    • Save up to 30 programs.

    • Lockable Programs

    • Electronic HV (HF) and Lift Start for TIG

    • .030"-.035" Wire diameter(larger optional drive rolls sizes and types available)

    • 24 Series Euro fast connect MIG gun

    • 8" spool (10 to 12 lbs)

    • Dual Voltage 120/240V

  • NEED TO KNOW:

    • Digital IGBT Inverter construction

    • Large 5.1" 720 Resolution TFT Display

    • MIG/AC/DC TIG/Stick/Spool Gun

    • MIG, AC/DC Pulse TIG, DC Stick function

    • E6010 capable

    • 60% Duty Cycle @ 275A MIG/TIG

    • 60% Duty Cycle @ 250A MIG/ 200 A Stick

    • Max 275A for MIG/TIG, 200A Stick

    • Adjustable MIG/Stick Arc Force

    • Save up to 16 programs

    • HV (Electronic HF), Live Lift Start and Lift with Remote for TIG

    • 4 AC Wave Forms

    • AC and DC Pulse TIG with Adjustable DC Pulse Wave Form Control

    • .023-.045" Wire diameter with optional drive rolls

    • .035"-.045" Standard drive roll size

    • Weld with solid wire or flux-core

    • 36 Series Euro fast connect MIG gun

    • 12" spool (approx. 30-44 lbs)

    • 8" spool (approx. 10-12 lbs) capable with adapter

    • Dual Voltage 120/240V

    • Improved PowerSet mode for fast setup and easy use

  • NEED TO KNOW:

    • Heavy Duty IGBT module construction

    • MIG/DC TIG/ Stick/Carbon Arc function

    • 240 1 phase and 480V 3 phase operation

    • 60% Duty Cycle @ 400A (480V 3 ph)

    • 60% Duty Cycle @ 250A (240V 1ph)

    • Heavy Duty Separate Wire Feeder

    • .035"-.062" Range with Optional Drive Rolls

    • 8"-12" spool (10 to 44lbs)

    • Heavy Duty Industrial Design

    • Integrated/removable cart

  • NEED TO KNOW:

    • Digitally Controlled IGBT Inverter

    • MIG/Stick function

    • Manual MIG

    • Synergic Single Pulse, Double Pulse MIG

    • Stick Function

    • Spool Gun and Push-Pull Ready

    • 350A MIG/350A Stick maximum output

    • 60% Duty Cycle at 350A MIG/350A Stick

    • .030"-.062" standard wire capability for Synergic mode

    • Adjustable inductance/arc force

    • Volt, Amp and Memory displays

    • Use 8" or 12" spools

    • Euro-Quick Connect for the 36 series MIG gun

    • Aluminum Push/Pull capable

    • Water Cooler for MIG Gun

    • Includes Cart

    • Separatable Wire Feeder/ Power source

TIG WELDERS

  • NEED TO KNOW:

    • Dependable IGBT inverter

    • New Digital internal design

    • Commercial 35% Duty Cycle at 140A

    • DC Stick/DC Lift TIG functions

    • 120V/240V Dual Voltage

    • Adjustable Hot Start

    • Adjustable Arc Force control

    • Stepless adjustment

    • Impact resistant carry case

  • NEED TO KNOW:

    • Dependable IGBT inverter

    • Commercial 35% Duty Cycle at 160A

    • DC Stick/TIG functions

    • High Frequency and Lift TIG start

    • Foot Pedal capable

    • 120V/240V  Dual Voltage

    • Adjustable Hot Start

    • Adjustable Arc Force Control

    • Stepless adjustmen

  • NEED TO KNOW:

    • Dependable IGBT inverter

    • Commercial 35% Duty Cycle at 160A

    • DC Stick/TIG functions

    • High Frequency and Lift TIG start

    • Foot Pedal capable

    • 120V/240V  Dual Voltage

    • Auto-adaptive Hot Start

    • Auto-regulated Arc Force control

    • Stepless adjustment

    • Impact resistant carry case

  • NEED TO KNOW:

    • Dependable Digitally Controlled IGBT inverter

    • New simplified internal design

    • Commercial 35% Duty Cycle at 200A

    •  E6010 function for Cellulosic Rods

    • DC Stick/Live Lift TIG functions

    • 120V/240V Dual Voltage

    • Adjustable Hot Start

    • Adjustable Arc Force control

    • 1 amp increment adjustment

  • NEED TO KNOW:

    • Dependable IGBT Digital inverter

    • New heavy duty internal design

    • Commercial 35% Duty Cycle at 200A

    • Dedicated seting for for E6010/Cellulosic Rods

    • DC Stick/Lift/Live lift TIG functions

    • 120V/240V Dual Voltage

    • Adjustable Hot Start

    • Adjustable Arc Force control

    • Stick VRD and Anti-Stick function

    • TIG Downslope and Postflow Control

    • Pedal/2T/4T function

    • Optional Foot Pedal

  • NEED TO KNOW:

    • Reliable IGBT Power Modules

    • Digital Microprocessor control

    • 35% duty cycle

    • Top performer with E6010 and 7018

    • 250A DC Stick/280A DC TIG

    • DC TIG with pulse up to 250 Hz

    • VRD function for improved safety while welding with Stick process

    • 1 and 3 phase input capable

  • NEED TO KNOW:

    • Dependable IGBT inverter design

    • Industrial 60% Duty Cycle at 300 Amps

    • Dedicated Setting for E6010

    • Adjustable Hot Start

    • Adjustable Arc Force Control

    • Stepless adjustment

    • DC Lift TIG capable

    • Proven, reliable performance

  • NEED TO KNOW:

    • Digitally controlled  IGBT Inverter

    • 35% Duty Cycle at 200 Amps (240V)

    • Dual Voltage 120/240V

    • DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Programmable Pulse to 500Hz

    • Adjustable Stick Hot Start/Arc Force

    • 9 Channel Memory

    • Down to 3 Amp operation

    • Compact design

  • NEED TO KNOW:

    • Dependable IGBT inverter

    • Analog style panel, digital control

    • Commercial, 35% Duty Cycle at 200 amps

    • DC TIG/DC Stick functions

    • HF or Lift TIG Start

    • Pulse up to 250Hz

    • Adjustable Stick Arc Force

    • Down to 5 amp start/operation

    • 120V/240V operation

  • NEED TO KNOW:

    • Digitally controlled IGBT inverter

    • Analog style controls

    • 120V/240V Dual Voltage

    • 35% Duty Cycle at 185 Amps/ 240V

    • 35% Duty Cycle at 125 Amps/ 120V

    • AC/DC TIG, DC Stick functions

    • Simple to use TIG pulse @ 1 or 50 Hz

    • HF or Lift TIG start

    • AC Frequency/Balance control

    • Standard AC Advanced Square Wave

    • HV Start (Solid State HF Type)

  • NEED TO KNOW:

    • Digitally Controlled IGBT Inverter

    • Analog style control

    • 120V/240V Dual Voltage

    • Industrial 60% Duty Cycle at 200 amps

    • AC/DC TIG/DC Stick functions

    • HV and Lift TIG start

    • Fan and Cooler Control Technology

    • Pulse up to 150Hz in AC or DC

    • Standard Advanced AC Square Wave

    • Arc force control for Stick

  • NEED TO KNOW:

    • 120/240V IGBT Module inverter design

    • PFC (Power Factor Correction)

    • Digital Microprocessor Control

    • Commercial 60% Duty Cycle at 210 Amps

    • AC/DC TIG/DC Stick functions

    • Improved Heavy Duty HF Start

    • AC Frequency/Balance control

    • 3 wave AC Wave forms, Advanced Square, Soft Square, and Triangular

    • Standard and Advanced AC pulse

    • Adjustable Stick Hot Start/Arc Force

    • 9 Channel Programmable Memory

    • Electronic HV Start replaces older HF point gap starting

    • Fan runs on demand when arc starts and terminates automatically after arc stops.

  • NEED TO KNOW:

    • Rugged IGBT Module inverter

    • Simple Analog Input, Reliable Digital Control of parameters

    • Industrial 60% Duty Cycle at 250 Amps

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 500 Hz  in AC or DC

    • AC Frequency/Balance control

    • Standard AC Advanced Square Wave

    • Arc force control

    • Spot weld timer

    •  HV Start.(Solid State HF Type)

    •  Fan-On-Demand

  • NEED TO KNOW:

    • Rugged Digital IGBT Inverter

    • Industrial 60% Duty Cycle at 250 Amps

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 500 Hz DC; 250 Hz AC

    • Advanced Square, Soft Square, Triangular, and Sine wave forms

    • Adjustable Stick Arc force and Hot Start Control

    • Advanced AC Pulse

    • 120V/240V Operation

    • Electronic HV Start replaces older HF point gap starting

    • Fan runs on demand when arc starts and terminates automatically after arc stops.

  • NEED TO KNOW:

    • Rugged IGBT Module inverter

    • Analog Input with Digital Control

    • Industrial 60% Duty Cycle at 315 Amps

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 750Hz in AC or DC

    • AC Frequency control up to 500Hz

    • AC Balance control 10-90%

    • Standard AC Advanced Square Wave

    • Stick Arc Force control

    • New, compact case design

    • HV Start (Solid State HF Type)

    • Fan on demand


    • Rugged IGBT Module Inverter

    • Digital Microprocessor

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 500 Hz DC; 250 Hz AC

    • Advanced Square, Soft Square, Triangular, and Sine wave forms

    • Adjustable Arc force and Hot Start

    • 9 programmable channels to save favorite settings

    • Advanced AC Pulse

    • 240V 1 ph

    • Electronic HV Start replaces older HF point gap starting

    • Fan runs on demand when arc starts and terminates automatically after arc stops.

  • NEED TO KNOW:

    • Rugged IGBT Module Inverter

    • Digital Microprocessor

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 500 Hz DC; 250 Hz AC

    • Advanced Square, Soft Square, Triangular, and Sine wave forms

    • Adjustable Arc force and Hot Start

    • 9 programmable channels to save favorite settings

    • Advanced AC Pulse

    • 480V 3 phase input

    • Electronic HV Start replaces older HF point gap starting

    • Fan runs on demand when arc starts and terminates automatically after arc stops.

  • NEED TO KNOW:

    • Rugged Digital IGBT Inverter

    • Commercial-level 35% Duty Cycle at 400 Amps

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 500 Hz DC; 250 Hz AC

    • Advanced Square, Soft Square, Triangular, and Sine wave forms

    • Adjustable Stick Arc force and Hot Start Control

    • Advanced AC Pulse

    • 240V 1 and 3 Phase Operation

    • Electronic HV Start replaces older HF point gap starting.

    • Fan runs on demand when arc starts and terminates automatically after arc stops.

  • NEED TO KNOW:

    • Rugged Digital IGBT Inverter

    • Commercial-level 35% Duty Cycle at 400 Amps

    • AC/DC TIG/ DC Stick functions

    • HF or Lift TIG start

    • Pulse up to 500 Hz DC; 250 Hz AC

    • Advanced Square, Soft Square, Triangular, and Sine wave forms

    • Adjustable Stick Arc force and Hot Start Control

    • Advanced AC Pulse

    • 3 Phase 480V Power Input and Operation

    • HF point gap starting

    • Fan runs continuously

  • NEED TO KNOW:

    • 230 Amp AC/DC Pulse TIG, 200 Amp AC/DC Stick.

    • Large 5.1" Hi Definition LCD color screen.

    • Independent Amperage adjustment for EP and EN half cycles (Independent Amplitude).

    • Split wave form control for AC.

    • 2 Amp DC and 3 Amp AC Start.

    • Up to 400 Hz AC frequency.

    • DC pulse wave form shaping.

    • Standard and Adv. AC pulse

    • Standard AC Pulse Freq. 400 Hz

    • Adv. AC Pulse 10 Hz

    • DC Pulse Frequency 999.9 Hz

    • 5 AC wave forms.

    • Advanced Power Set Mode for easy setup.

    • No pop-up screens.  Easy to navigate.

    • All main settings visible at a glance.

    • Fan and Cooler Control Technology.

    • 70% Duty Cycle at max output.

    • Dual Voltage 120/240V, auto sensing.

  • NEED TO KNOW:

    • 330 Amp AC/DC Pulse TIG, 250 Amp AC/DC Stick.

    • 220/240V 1 and 3 Phase

    • Large 5.1" Hi Definition LCD color screen.

    • Independent Amperage adjustment for EP and EN half cycles (Independent Amplitude).

    • Split wave form control for AC.

    • 3A Start AC/ 2A Start DC

    • Up to 400 Hz AC frequency.

    • DC pulse wave form shaping.

    • Standard and Adv. AC pulse

    • Standard AC Pulse Freq. 400 Hz

    • Adv. AC Pulse 10 Hz

    • DC Pulse Frequency 999.9 Hz

    • 5 AC wave forms.

    • Advanced Power Set Mode for easy setup.

    • No pop-up screens.  Easy to navigate.

    • All main settings visible at a glance.

    • Fan and Cooler Control Technology.

  • NEED TO KNOW:

    • 330 Amp AC/DC Pulse TIG, 250 Amp AC/DC Stick.

    • 480V 3 Phase only

    • Large 5.1" Hi Definition LCD color screen.

    • Independent Amperage adjustment for EP and EN half cycles (Independent Amplitude).

    • Split wave form control for AC.

    • 3A Start AC/ 2A Start DC

    • Up to 400 Hz AC frequency.

    • DC pulse wave form shaping.

    • Standard and Adv. AC pulse

    • Standard AC Pulse Freq. 400 Hz

    • Adv. AC Pulse 10 Hz

    • DC Pulse Frequency 999.9 Hz

    • 5 AC wave forms.

    • Advanced Power Set Mode for easy setup.

    • No pop-up screens.  Easy to navigate.

    • All main settings visible at a glance.

    • Fan and Cooler Control Technology.

  • NEED TO KNOW:

    • 500 A AC/DC Pulse TIG, 400 A AC/DC Stick (480V 3 phase)

    • 400A AC/DC Pulse TIG, 315A AC/DC Stick (240V 1 phase)

    • Large 720P High Definition LCD color screen

    • Independent Amperage adjustment for EP and EN half cycles (Independent Amplitude)

    • Split wave form control for AC

    • 10A Start AC/ 5A Start DC

    • Up to 400 Hz AC frequency

    • DC pulse wave form shaping

    • Standard and Adv. AC pulse

    • Standard AC Pulse Freq. 400 Hz

    • Adv. AC Pulse 10 Hz

    • DC Pulse Frequency 999.9 Hz

    • 5 AC wave forms

    • Advanced Power Set Mode for easy setup

    • No pop-up screens.  Easy to navigate

    • All main settings visible at a glance

    • Fan and Cooler Control Technology

    • Includes Cooler and Cart

Contact us.

Joydesignsllc@gmail.com

Parkersburg, WV
